Revision

1.0

Last Updated

2025/09/17

Problem

Validation failed: DCB_Resistance = (value) out of rance (0.03-0.04)

Explanation of Problem

Resistance error encountered. Please check the actual value to determine the actual issue below

Possible Issue - IQC computer may need calibration

If the resistance value shown is withing the range 0.03 - 0.04 (in screenshot above the value is 0.036 which is within the range) then computer requires calibration.

See Solution below.

Possible Issue - Resistance is outside the actual range

If the resistance value shown is outside the range 0.03 - 0.04 (below 0.03 or above 0.04) then battery may be faulty. Contact QC Supervisor for next steps.

Solution for computer calibration

Contact Quality Engineer (Bill Kaiser)

Contact Supervisor (Blaise Kalubi)

Contact IT member (George Bica)

They will contact Generac support for calibration steps. Do not proceed with more testing.
